Model | 13X Molecular Sieve | |||
Color | Beige | |||
Nominal pore diameter | 10 angstroms | |||
Shape | Sphere | Pellet | ||
Diameter | 1.7-2.5 (mm)
| 3.0-5.0 (mm)
| 1.6 (mm)
| 3.2 (mm)
|
8*12 (mesh) | 4*8 (mesh) | 1/16 (inch) | 1/8 (inch) | |
Bulk density (g/ml) | ≥0.64 | ≥0.64 | ≥0.61 | ≥0.61 |
Crushing strength (N/PC) | ≥25.0 | ≥80.0 | ≥25.0 | ≥45.0 |
Size ratio up to grade (%) | ≥98.0 | ≥98.0 | ≥95.0 | ≥95.0 |
Static H2O adsorption (%) | ≥25.0 | ≥25.0 | ≥25.0 | ≥25.0 |
Static CO2 adsorption (%) | ≥17.0 | ≥17.0 | ≥17.0 | ≥17.0 |
H2O content (%) | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Wear ratio (%) | ≤0.20 | ≤0.20 | ≤0.40 | ≤0.40 |
PRODUCTS DESCRIPTION
Product Introduction:
13X APG Molecular Sieve, is the sodium form of the type X crystal and has a much larger pore opening than the type A crystals. It will adsorb molecules with a kinetic diameter of less than 9 angstrom(0.9nm) and exclude those larger.
FEIZHOU Zeolite 13X APG Molecular Sieve, the highest theoretical capacity of the common adsorbents and very good mass transfer rates. It can remove impurities too larger to fit into a type A crystal and is commonly used to separate N2 from O2.
Chemical Molecular Formula: Na2O·Al2O3·2.45SiO2·6.0H2O. (SiO2:Al2O3≈2.6-3.0).
Technical Parameter:
Model | 13X APG Molecular Sieve | |||
Color | Beige | |||
Nominal pore diameter | 10 angstroms | |||
Shape | Sphere | Pellet | ||
Diameter | 1.7-2.5 (mm)
| 3.0-5.0 (mm)
| 1.6 (mm)
| 3.2 (mm)
|
8*12 (mesh) | 4*8 (mesh) | 1/16 (inch) | 1/8 (inch) | |
Bulk density (g/ml) | ≥0.64 | ≥0.64 | ≥0.61 | ≥0.61 |
Crushing strength (N/PC) | ≥25.0 | ≥75.0 | ≥25.0 | ≥45.0 |
Size ratio up to grade (%) | ≥98.0 | ≥98.0 | ≥95.0 | ≥95.0 |
Static H2O adsorption (%) | ≥25.0 | ≥25.0 | ≥25.0 | ≥25.0 |
Static CO2 adsorption (%) | ≥18.0 | ≥18.0 | ≥17.0 | ≥17.0 |
H2O content (%) | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Wear ratio (%) | ≤0.20 | ≤0.20 | ≤0.40 | ≤0.40 |
Typical Application: Removal of H2O from air for air cryo separation application.
Warranty: By National Standard HG/T 2690-2012.
Free consultation during the warranty period.
Attention: Store in a cool & dry place.
Normal Package: 25KG or 30KG cartons 13X Molecular Sieve with vacuum bags inside.
